Référence | N° PIECE | DESCRIPTION | STANDARD | TYPE | Tarif Public € HT | Commander |
---|---|---|---|---|---|---|
DK10810.6 | Valise de transport noir |
65.28 € HT |
||||
9009001 | Huile pour embrayage | 90ml |
1.49 € HT |
|||
DK11102-1 | 2 | Capot intermediare |
56.94 € HT |
|||
DK11103 | 3 | Capot supérieur |
48.61 € HT |
|||
105045 | 38 | Vis à six pans creux (Quantité nécessaire : 4 pièces) | M5x45 |
0.50 € HT |
||
539019 | 44 | Vis (Quantité nécessaire : 5 pièces) | 3,9x19 |
0.21 € HT |
||
8715240 | 59 | Câble électrique (Quantité nécessaire : 2 pièces) | 1,5 |
2.22 € HT |
||
8015211 | 65 | Interrupteur d'alimentation | 230V/110V |
22.09 € HT |
||
DK11201.6 | 100 | Boitier d'engrenage |
97.22 € HT |
|||
DK12202 | 105 | Anneau de serrage |
29.17 € HT |
|||
DK11204 | 110 | Disque de support |
3.33 € HT |
|||
DK11205.6 | 112 | Douille d'insertion |
17.37 € HT |
|||
DK11206.6 | 115 | Arbre de carottage sortie M16 |
63.89 € HT |
|||
DK11208.6 | 119 | Arbre à pignon |
36.67 € HT |
|||
DK12209 | 120 | Pignon |
26.28 € HT |
|||
DK11210.6 | 125 | Manchon central |
53.48 € HT |
|||
DK11215.6 | 130 | Roue d'entraînement |
26.39 € HT |
|||
DK10218 | 135 | Disque de frein (Quantité nécessaire : 2 pièces) |
3.49 € HT |
|||
DK10219 | 145 | Bague d'embrayage |
7.03 € HT |
|||
DK10221 | 150 | Roulement à douille |
4.27 € HT |
|||
DK11230.6 | 160 | Raccord d'aspiration |
38.89 € HT |
|||
DK11234.6 | 165 | Clip de verrouillage |
13.61 € HT |
|||
4504011 | 170 | Anneau | 7,65x1,78 |
2.78 € HT |
||
4608144 | 175 | Joint de tige | 8x14x4 |
3.89 € HT |
||
1908141 | 180 | Rondelle de serrage | PS8x14x1 |
0.21 € HT |
||
1910161 | 185 | Rondelle de serrage | PS10x16x1 |
0.21 € HT |
||
8900014 | 190 | Poignée |
13.49 € HT |
|||
6062900 | 192 | Roulement à billes | 629 |
5.89 € HT |
||
6060044 | 195 | Roulement à billes | 6004 2RS |
10.42 € HT |
||
6310100 | 205 | Douille à aiguilles (Quantité nécessaire : 2 pièces) | HK1010 |
5.89 € HT |
||
5578002 | 210 | joint o ring | RDR78x2 |
1.07 € HT |
||
5016307 | 235 | Joint d'étancheite | A16x30x7 |
5.56 € HT |
||
4028142 | 250 | Rondelle à ressort | 28x14,2x1,5 |
3.33 € HT |
||
1012015 | 260 | Ecrou | BM12x1,5 |
0.57 € HT |
||
2504010 | 265 | Clavette | 4m6x10 |
0.34 € HT |
||
3515001 | 270 | Bague de maintien | A15x1 |
0.21 € HT |
||
3520012 | 275 | Bague de maintien | A20x1,2 |
0.43 € HT |
||
2542175 | 280 | Bague de maintien | J42x1,75 |
0.62 € HT |
||
3004010 | 285 | Clavette | A4x4x10 |
0.43 € HT |
||
105070 | 290 | Vis à six pans creux | M5x70 |
0.57 € HT |
||
105050 | 295 | Vis à six pans creux (Quantité nécessaire : 3 pièces) | M5x50 |
0.50 € HT |
||
506040 | 300 | Vis papillon | M6x40 |
1.11 € HT |
||
1805000 | 310 | Rondelle de blocage (Quantité nécessaire : 4 pièces) | SM5 |
0.07 € HT |
||
1806125 | 315 | Rondelle | A6,4 |
0.07 € HT |
